Standards:
Powerline: HomePlug AV
Ethernet: IEEE 802.3 10/100 Auto MDI/MDIX
Energy Saving: EuP Compliance
Protocol: TCP/IP, IGMP, QoS CSMA/CA
Data Transfer rate: Up to 500Mbps over powerline
Transmission Range: Up to 300m over powerline
Frequency band: 2Mhz to 30Mhz
Security & Protection:
128-bit AES encryption (enabled with Simple Connect button)
Modulation Technology:
OFDM 1024/256/64/16/8 QAM, QPSK, BPSK and ROBO
Modulation Scheme
Power Consumption:
Normal: less than3 Watt
Power save: less than 1 Watt Average
Operating System:
Windows 98SE/ME/2000/2003/XP/Vista, Windows7, Linux,
Mac OS
Power Requirement: AC 100 ~240V, 50~60Hz
Temperature:
Operating: 0° to 40° Celsius
Non-Operating : -25° to 70° C
Humidity:
Operating: 10%~90%, Non-condensing
Non-Operating : 5%~90%, Non-condensingCasing Color: White
LED Indicators:
Power, Ethernet, Data
External Connectors:
1 x Power Plug
1 x Ethernet LAN Port
1 x Button to press for an easy
secure pairing between plugs
and for a reset to return to
initial configuration
Additionally, the other 7WHP530 extend signal wirelessly with high speed transfers without the need for unsightly network
cables
המוצר נועד לרשת חשמל חד פאזית
לא עובד עם מפצל חשמל
